WRAS Approved PPR Pipes & 100% Brass Fittings Manufacturer in the UAE

  • ISO 9001:2015
  • ISO 14001:2015
  • DIN 8077/8078
  • DVS 2207
  • WRAS Approved Material

Premium PPR Pipes.Unbreakable German.Foundations.

RakPlus® engineers PP-R pipes and brass-insert fittings to DIN 8077/8078 and DVS 2207 in our UAE facility — specified across the GCC for residential, commercial, and industrial potable water systems.

RakPlus 63x10,5mm SDR6 / PN20 horizontal green PP-R pipe on a futuristic white architectural telemetry display with floating glassmorphic DIN/PN20/WRAS spec cards.
Pressure Class Range

PN10 · PN16 · PN20 · PN25

Four pressure classes cover every UAE plumbing requirement from residential cold-water distribution to industrial high-pressure risers.

PN10 · SDR1110bar
PN16 · SDR7.416bar
PN20 · SDR620bar
PN25 · SDR525bar
Density (ISO 1183)905kg/m³
Thermal Cond. (DIN 52612)0.24W/m·K
Melt Flow (ISO 1133)≤0.3g/10min
Charpy Impact (ISO 179/1eU)NBNo Break
  • 01
    Polymer100% Polymer
  • 02
    Brass100% Brass
  • 03
    WRASWRAS approved material
  • 04
    50yr50 years guaranteed service life
RakPlus Ø32x1" PP-R TYP3 green transition female elbow with golden hex brass insert on a white architectural drafting surface with silver isometric CAD grid and golden 100% BRASS callout card.

100% Brass Insert Transitions

Solid Brass InsertDIN 8076Zero-Leak Seal.

Precision-machined solid brass insert — never plated, never hybrid. Engineered for thermal-cycling durability and zero-galvanic compatibility with the PP-R pipe matrix.

Explore All Products Range →

DIN 8077/8078

Material

100% Virgin Polypropylene Random-Copolymer

Pure polymer matrix delivering molecular stability from 0 °C to 70 °C continuous, with short-term peaks up to 100 °C.

Type 3 · PP-R

Brass Inserts

Fittings

100% Brass Insert Transitions

Precision-machined brass inserts engineered for thermal cycling durability and zero-galvanic compatibility with the PP-R pipe matrix.

Never plated · Never hybrid

WRAS Approved

Potable Water

Independent Potable Water Certification

Every RakPlus pipe and brass-insert fitting carries WRAS approval for contact with drinking water — the international benchmark demanded by consultants across the GCC.

UK Water Regulations Advisory Scheme

German Standard Engineering · Made in UAE

EVOLVE. EXPAND. EMPOWER.

Premium PP-R Piping Systems in the UAE. Manufactured to strict German Standard DIN 8077/8078.

DIN 8077 / 8078 · DVS 2207

German Standard
Engineering.

Manufactured using modern technology in strict accordance with German standards DIN 8077/8078. Every pipe is produced with precision tooling and DVS 2207 certified welding processes.

PN10to PN25
20mmto 160mm
SDR6to SDR11
50yrService Life
ISO 9001:2015ISO 14001:2015DIN 8077/8078DVS 2207EN ISO 15874-2
ISO 9001:2015 · ISO 14001:2015

Trusted Across
the GCC.

Trusted across the GCC for residential, commercial, and industrial water transmission. ISO 9001:2015 certified quality with a 50-year guaranteed service life.

50-Year Guarantee

100% Safe for
Potable Water.

Exceeding DIN 8077/8078 German Standards for Hygiene. RAKPLUS PPR systems are WRAS approved for contact with potable drinking water and carry a 50-year manufacturer guarantee.

The RakPlus Standard

Evolve. Expand. Empower.

RakPlus is the UAE’s premium PPR pipe and fittings manufacturer — engineered to German Standard DIN 8077/8078. Every system is built from 100% Polymer with 100% Brass insert fittings, WRAS approved for contact with potable water, and backed by a 50-year manufacturer guarantee.

Specified by engineers across Dubai, Abu Dhabi, Sharjah, and the wider GCC for hotels, hospitals, high-rise residential towers, and industrial facilities. Pressure rated PN10 to PN25. Diameters 20 mm to 160 mm. Continuous operating temperature 70°C with 100°C short-term peaks.

Certified:
DIN 8077/8078DVS 2207EN ISO 15874-2ISO 9001:2015ISO 14001:2015WRAS Approved

RakPlus — Direct Answers

Frequently Asked QuestionsPPR Pipes & Fittings in the UAE

Direct, fact-checked answers to the four most-asked commercial queries about RakPlus PPR pipe systems. All figures below are sourced from the RakPlus technical submittal and WRAS certification documents.

01.Why choose RakPlus PPR pipes for UAE high-temperature plumbing systems?

RakPlus PPR pipes are engineered from 100% Virgin Polypropylene Random Copolymer (PP-R Type 3) — a molecularly stable matrix that resists creep, scaling, and chlorine degradation. Every brass-insert transition fitting is machined from 100% Brass, never plated, never hybrid. The dual-purity construction preserves mechanical integrity at 95°C continuous operating temperatures and 100°C short-term peaks — the thermal envelope of high-temperature plumbing systems in the UAE. This is why specifying engineers in Dubai, Abu Dhabi, and the wider GCC select RakPlus for hotels, hospitals, and high-rise residential towers.

02.Are RakPlus PPR piping systems certified for potable drinking water?

Yes. Every RakPlus PPR pipe and brass-insert fitting is WRAS approved (Water Regulations Advisory Scheme), the international benchmark for materials in contact with potable drinking water. WRAS approval is independently tested and certified, and is the standard required by consultants and municipalities across the UAE, Saudi Arabia, Qatar, Kuwait, Bahrain, and Oman. The certification applies to the complete RakPlus PP-R system — pipes, fittings, and brass-insert transitions.

03.What is the certified operating lifespan of RakPlus systems?

Every RakPlus PPR system carries a 50-year manufacturer service life guarantee. The 50-year warranty is the longest published guarantee offered by any PPR pipe manufacturer in the UAE, and is written into every RakPlus commercial quotation. The certified 50-year service life is a direct consequence of the 100% Polymer pipe matrix, 100% Brass insert fittings, and WRAS approved material specification, manufactured to German Standard DIN 8077/8078 and welded to DVS 2207.

04.What temperature and pressure ratings do RakPlus PPR pipes handle?

RakPlus PPR pipes are available in four pressure classes — PN10 (SDR 11), PN16 (SDR 7.4), PN20 (SDR 6), and PN25 (SDR 5) — covering the full range of UAE plumbing requirements from residential cold-water distribution to industrial high-pressure risers. Operating temperature ratings are 70°C continuous with 100°C short-term peaks across all classes, with PN20 and PN25 rated for up to 95°C in hot-water recirculation systems. Pipe diameters are stocked from 20 mm to 160 mm. All pressure and temperature figures are published in the RakPlus technical datasheet and are available on request.

PPR & Plumbing Technical Terms — Defined

Authoritative definitions of the four most-cited benchmarks used in PPR pipe specification across the UAE and GCC.

WRAS
Water Regulations Advisory Scheme — UK certification confirming plumbing materials are safe for contact with potable drinking water. RakPlus PPR pipes and brass-insert fittings carry WRAS approval, the international benchmark demanded by consultants and municipalities across the UAE and GCC.
SDR
Standard Dimension Ratio — outer diameter divided by wall thickness. A lower SDR means a thicker wall and a higher pressure rating. RakPlus PPR pipes are manufactured in SDR 11 (PN10), SDR 7.4 (PN16), SDR 6 (PN20), and SDR 5 (PN25).
PN20
Pressure class rating for a pipe that withstands a continuous operating pressure of 20 bar at 20°C. RakPlus PN20 PPR pipes have an SDR of 6 and are the most common specification for hot-water recirculation loops and high-rise residential risers across the GCC. 70°C continuous, 100°C short-term peak.
DIN 8077/8078
German Standard dimensional and quality specifications for polypropylene (PP-R) pressure pipes. RakPlus PPR pipes are manufactured in strict accordance with DIN 8077 (pipe dimensions) and DIN 8078 (general quality), welded to DVS 2207 — the European and Gulf consulting-engineer standard.

RakPlus UAE — Verified Specifications

Industrial Plumbing Solutions for the UAE — Engineered to Outlast

RakPlus delivers industrial plumbing solutions and high-pressure water systems built from 100% Polymer pipes with 100% Brass fittings. Every system is WRAS approved for potable water and engineered to withstand the UAE climate for a guaranteed 50 years of service.

Catalogue p.03 — Verified Applications

  • 01

    Potable Hot & Cold Water

    WRAS approved material for residential, commercial, and high-rise risers — the primary RakPlus application across the UAE and GCC.

    DIN 8077/8078 · WRAS

  • 02

    HVAC & Compressed Air

    Chemically inert PP-R matrix for chilled water, condenser, and low-pressure compressed air distribution in mechanical rooms.

    EN ISO 15874-2

  • 03

    Rainwater Utilization

    UV-stabilised green and yellow pipe variants for non-potable rainwater harvesting, stormwater reuse, and greywater recycling networks.

    DVS 2207 Welding

  • 04

    Agricultural & Irrigation

    Corrosion-resistant networks for drip-feed irrigation, hydroponic loops, and greenhouse water distribution across arid-climate projects.

    DIN 8078 Quality

  • 05

    Swimming Pool & Spa

    Chlorine-resistant 100% polymer matrix for pool balancing tanks, spa return lines, and chlorine dosing systems.

    Chemical Resistance Verified

  • 06

    Corrosive Industrial Fluids

    Chemically inert to acids, alkalis, and desalination brine — engineered for industrial process water, RO reject, and chemical dosing.

    Catalogue p.24 Chemical Chart

DIN / ISO / DVS Compliance Cluster

  • DIN 8077PP-R Pipe Dimensions
  • DIN 8078PP-R General Quality
  • DVS 2207Fusion Welding Parameters
  • EN ISO 15874-2PP-R Piping System Standard
  • ISO 9001:2015Quality Management
  • ISO 14001:2015Environmental Management
  • WRASPotable Water Approval
  • 50 yrService Life Guarantee
